Orbit · logo system
A core, and the bodies that travel it
The existing ring, evolved. The market sits at the centre; protocols and partners move around it. The full name is the only wordmark — EGP never appears in the same lockup.
01 · Construction
Drawn on a 100-unit grid
All values scale proportionally. Both bodies sit centred on the ring path and knock a 2-unit gap out of it, so the ring reads as passing behind them. The emerald body always leads, on the upper-right diagonal.
- Orbit radius
- 34 u
- Ring weight
- 5 u
- Core radius
- 13 u
- Bodies
- 9 u / 7 u
- Body positions
- 45° / 225°
- Knockout gap
- 2 u
02 · Lockups
Three arrangements. Nothing else.
Minimum widths — horizontal 180 px, stacked 120 px, mark 16 px.
03 · Size behaviour
The core never changes
Below 48 px the small white body is dropped; below 32 px both bodies go and the ring thickens to hold its weight. Clear space on all four sides equals the core diameter — nothing enters it, including the site's grid lines.
04 · Colour
Full colour on black is primary
The rest are fallbacks. Nothing outside this palette enters the identity.
05 · Don't
Four things that break it
- Never pair the mark with “EGP”. The abbreviation is a separate identity.
- Never rotate. The bodies hold the 45° diagonal.
- Never recolour to match a partner protocol’s palette.
- Never stretch. Scale proportionally only.
06 · Assets
Download the marks
Lockups are PNG with the wordmark baked in; marks are SVG. Regenerate everything with `node scripts/brand-assets.mjs` rather than editing a file by hand.
